अल्टिसिस रेडियोग्राफी सिस्टम
nan आईएनआर/टुकड़ा
उत्पाद विवरण:
- उपयोग करें For Hospital Use
- प्रॉडक्ट टाइप Semi-Automated
- मटेरियल Mild Steel
- के लिए उपयुक्त For Patient Use
- वज़न पौंड (पौंड)
- एप्लीकेशन For Hospital amd Clinic Purpose
- अधिक देखने के लिए क्लिक करें
X
अल्टिसिस रेडियोग्राफी सिस्टम मूल्य और मात्रा
- 1
- टुकड़ा/टुकड़े
- टुकड़ा/टुकड़े
अल्टिसिस रेडियोग्राफी सिस्टम उत्पाद की विशेषताएं
- Mild Steel
- For Patient Use
- Semi-Automated
- For Hospital amd Clinic Purpose
- पौंड (पौंड)
- For Hospital Use
अल्टिसिस रेडियोग्राफी सिस्टम व्यापार सूचना
- चेक टेलीग्राफिक ट्रांसफर (T/T) कैश इन एडवांस (CID) कैश एडवांस (CA)
- प्रति सप्ताह
- हफ़्ता
- ऑल इंडिया
उत्पाद वर्णन
ULTISYS is a versatile radiography system that offers a cost-effective set-up with a high degree of clinical flexibility.
overview
ULTISYS is a versatile radiography system that offers a cost-effective set-up with a high degree of clinical flexibility.
Features
- ULTISYS is a versatile radiography system that offers a cost-effective set-up with a high degree of clinical flexibility.
- ULTISYS System also provides scalability with a wide range of generator options and easy upgrade path to a full digital radiography system.
- ULTISYS System consists of : A Celling Free tube stand sliding on flat rails, four-way floating bucky table, and Vertical Bucky stand and high frequency generator with control console.
- Intuitive Control Console offering “Anatomical Programming (APR)” and optional "Automatic Exposure Control (AEC)"
- Offers the flexibility of examining patient from head to toe without essentially repositioning the patient.
- Ergonomic design offering a wide spectrum of clinical applications.
Tech nical specification
| GENERATOR | |||||
| Output Rating | 32kW | 40kW | 52kW | 68kW | 82kW |
| kV Range | 40-125kv | 40-125kV | 40-150kV | 40-150kV | 40-150kV |
| mA Range | 10-400mA | 10-500mA | 10-640mA | 10-800mA | 10-1000mA |
| mAs Range | 0.1-500mAs | 0.1-500mAs | 0.1-500mAs | 0.1-500mAs | 0.1-500mAs |
| 400mA@80kV | 500mA@80kV | 640mA@81kV | 800mA@85kV | 1000mA@82kV | |
| 320mA@100kV | 400mA@100kV | 500mA@104kV | 640mA@106kV | 800mA@102kV | |
| 250mA@125kV | 320mA@125kV | 400mA@130kV | 500mA@136kV | 640mA@128kV | |
|
|
| 320mA@150kV | 400mA@150kV | 500mA@150kV | |
| Leakage Radiation | <2mR/hr | <2mR/hr | <2mR/hr | <2mR/hr | <2mR/hr |
| CELLING FREE TUBE STAND | 4 WAY FLOATING TABLE TOP | ||||
| Tube rotation angle | ± 180° | Table Top | L : 2360mm X W : 760mm X H : 750 | ||
| Longitidinal Travel | 2500mm | Filtration 1.2mmAl | |||
| Brake Mechanism | Electro-magnetic | Max. Patient Weight 300kg Upgradable to 400 kg | |||
| Balance | Counter Weight | Bucky type | Fixed detector holder with integrated High Density Grid. | ||
| Tube centered to Bucky | Grid | Electro-Magnetic (Logitudinal and Transverse movement) | |||
| Fully counterbalance tube holding arm | Lock(Brake) | Ratio 8:1, 178 LP, Focal Distance : 100cm | |||
| BUCKY WALL STAND | X-RAY TUBE | ||||
| Vertical Travel | 1260mm | Anode Speed : Low and High | |||
| Brake Mechanism | Electro - magnetic | HU : 140 kHU to 400 kHU | |||
| Bucky Type | Fixed detector holder with integrated High Density grids |
|
| ||
| Grid | Focal distance: 150 cm |
| |||
